Home>Main Instruments>Spectrophotometer>Portable Spectrophotometers

NS810 Portable Spectrophotometer

Portable Cheap Accurate Spectrometer

The NS800 array spectrophotometer is an affordable entry-level spectrometer, new handheld spectrophotometer, developed with 3NH's proprietary core technology, features separates the light according to a certain wavelength interval, and adopts groups of sensor array to perform sensitive analysis. This design ensures high - speed, accurate, stable, and consistent measurements. NS810 has a compact design, is easy to handle and quick to get to the right colour, even on uneven surfaces of objects.


Key Highlights

  • d/8 (diffused illumination, 8-degree viewing angle)

  • Excellent Repeatability (ΔE * AB≤0.2)

  • Inter - instrument Error Control (ΔE * AB≤0.04)

  • Spectral Value/Graph, Colorimetric Value, Color Difference Value/Graph, PASS/FAIL Result and etc

  • Large 3.5 Inch Touch Screen Operation, Fully Automatic Calibration

  • Largest 58mm integrating sphere

NS810 Portable Spectrophotometer Instructions Operating Manual NS810 Portable Spectrophotometer PDF
This NS810 Instrument are Certified with
certify
1 Years Warranty (Additional support period of 3 years)

NS810 Spectrophotometer: Full-Scene Color Consistency Solution

NS810 spectrophotometer is developed by 3nh with independent intellectual property rights. It features with stable performance, precise measurement and powerful functions in the leading position of the same industry.


In the R&D process, 3nh scientists and engineers measured various color samples from dark to light, white to black, and other standard color boards provided by ISO (International Standardization Organization). The parameters of test results are integrating with international standards.




3nh also analyzed the parameters from Japan, American and Germany spectrophotometers. The differences of L*ab absolute value between them are within ±1.5. Compared the L*ab value between NS810 and Japan spectrophotometer, when measuring any color objects, the biggest L*ab difference is within ±1.0. This is a breakthrough of 3nh high technology which realizes to be fully compatible with international market.

NS810 Widely Applications

NS810 spectrophotometer is widely used in plastic, electronic, painting, coating, ink, textile, garment, printing and dyeing, food, medical, cosmetic, industries, scientific research institutes, schools and laboratories. It can measure reflectance spectrum and other color index precisely. NS810 spectrophotometer not only can help to perform color matching and color management studies, but also can control product quality management accurately. The instrument is equipped with high-end color management software which can connect PC to achieve more extension functions.



NS810 Portable Spectrophotometer


NS810 Specification


ModelNS810
Illumination/observation systemd/8 (diffused illumination, 8-degree viewing angle) Conforms to CIE No.15, GB/T 3978.
Integrating sphere SizeΦ58mm
Light SourceCombined LED sources
SensorSilicon photodiode array
Wavelength range400~700nm
Wavelength pitch10nm
Reflectance range0~200%
Measuring ApertureΦ8mm
Color SpaceCIE LAB, XYZ, Yxy, LCh, CIE LUV，LAB&WI&YI
Color difference FormulaΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00
Other Chromaticity DataWI(ASTM E313，CIE/ISO,AATCC, Hunter)， YI(ASTM D1925，ASTM E313), TI(ASTM E313，CIE/ISO), Metamerism Index (Mt), Strength Color Stain, Color Fastness
Observer2°/10°
IlluminantD65，A, C, D50，D55，D75，F1，F2(CWF)，F3，F4，F5，F6，F7(DLF)，F8，F9，F10(TPL5)F11(TL84), F12(TL83/U30)
Display DataSpectral Value/Graph, Colorimetric Value, Color Difference Value/Graph, PASS/FAIL Result, Color Offset, Color Simulation, color index setting(ΔE*94, ΔE*cmc, ΔE2000), tolerance prompt, reverse prompt, time setting, language setting, restore factory setting
Measurement Time1.2s
RepeatabilitySpectral Reflectance: standard deviation within 0.1%(400~700nm: within 0.2%)
Colorimetric Value: Standard deviation within DeltaE*ab 0.04 (Measurement conditions: white calibration plate measured 30 times at 5 seconds intervals after white calibration was performed.)
Inter Instrument AgreementWithin DeltaE*ab 0.2 (Average for 12 BCRA Series II color tiles)
DimensionL*W*H=90*77*230mm
Weight600g
BatteryLi-ion battery. 2800 times within 8 hours.
Lamp Life5 years, more than 1.6 million measurements
Display ScreenTFT 3.5inch, Capacitive Touch Screen
InterfaceUSB
Data Memory1000 Standards, 15000 Samples
Operating Temperature0~40℃（32~104°F）
Storage temperature -20~50℃（-4~122°F）
Standard AccessoryPower Adapter, Built-In Li-ion Battery, User Guide, PC Software（Download from the official website）, White and Black Calibration Cavity, Dust Cover
Optional AccessoryMicro Printer, Powder Test Box
NotesThe specifications are subject to change without notice.



Our Valued Clients

  • customer swaraj
  • customer nesling logo
  • partner axa
  • customer tatasky logo
  • Client mohani logo
  • customer hms logo
  • customer bell logo
  • Client lakhani

FAQs About NS810 Portable Spectrophotometers

Now our testing machines have been sold to more than 80 countries, like USA, Canada, Russia,UK, Italy, Germany, European , India, Pakistan, Philippine, Singapore, Malaysia,Thailand , Vietnam, Korea,Saudi Arabia,Brazil...and so on. We sell to the global market.

With centers in 20 countries, including India, Japan, USA, Germany, Singapore, China, South Korea, and Taiwan, Threenh Technology’ s service network aims to provide customers with convenient access to service globally. With over 1 million measuring instruments sold, our expertise is our greatest asset, enabling us to work with our customers on solutions to complex measurement challenges.

When detecting color differences, the first factors to consider when selecting a light source include its stability, directionality, lifespan, and the effectiveness of the ultimately obtained spectral curve. The illuminant of a colorimeter is a fixed bulb, such as a tungsten lamp，LED light or a long-life xenon lamp. However, for the same color sample, the results displayed by the instrument vary under different light sources. This is because different light sources cause different absorption and reflection of light on the sample, leading to differences in how both the human eye and the instrument perceive the color.

In general, the D65 light source is used in the application of coil steel inks for construction. The D65 light source is equivalent to average daylight. Most coil steel inks for construction are used outdoors, and sunlight is regarded as the standard light source in outdoor environments. For household appliance coil steel inks, due to their usage characteristics, they are mostly used indoors. Therefore, the A standard light source is adopted for color measurement of samples based on indoor lighting conditions. The A light source is a carefully specified tungsten light source. Other light sources, such as fluorescent light sources, can be used in many types of applications. For example, some textile factories use fluorescent light sources. Therefore, a reasonable light source should be selected as the mutually recognized measurement method based on actual usage conditions and user requirements. Once agreed upon by both parties, color measurement must be conducted under the same conditions. This helps reduce unnecessary systematic errors and human errors, achieving the optimal consistency in color measurement.

The 3nh high-precision spectrophotometric colorimeter adopts a combined LED light source with long lifespan and low power consumption, which includes UV (ultraviolet) and UV-excluded options. This design can meet the color difference detection needs of different users and supports the selection of multiple light source modes.

The Ideal Accurate and User - Friendly Spectrophotometer for Your Needs

This Spectrophotometer device measures the reflectivity，absorbance, transmittance, and fluorescence of light passing through samples, providing invaluable data for a wide range of applications, provide unrivaled accuracy for reliable results.

Selecting an appropriate spectrophotometer offers significant advantages for precision color analysis and quality control. When choosing an accurate and user - friendly spectrophotometer, consider factors such as wavelength range, sensitivity, sample handling options, and available software features. By investing in the right spectrophotometer, you can streamline your analytical processes, obtain more accurate results, and enhance the overall efficiency of your laboratory or industrial operations.

 Choosing the right model—whether portable, benchtop, or inline—aligns technology with specific industry needs, ensuring long-term reliability and optimized color management.

True color in chemistry is the color seen in a solution or compound in standardized conditions. It depends on electronic transitions in molecules, specifically absorption of a particular wavelength of light, and this depends on the structure of the compound.

A colorimeter is sufficient for basic, routine color checks, while a spectrophotometer is needed for precise, comprehensive color analysis—here’s the clear breakdown:

When a Colorimeter is Sufficient

  1. Simple color matching needs: Ideal for checking if a sample matches a predefined standard (e.g., basic paint batches, plastic parts with solid colors).

  2. Consistent lighting conditions: Works well when measurements are done under fixed, standard light sources (no need to account for varied light effects).

  3. Cost-sensitive, high-volume tasks: Perfect for production lines requiring fast, low-cost color checks without advanced data analysis.

When to Use a Spectrophotometer

  1. Precise color quantification: Necessary for measuring Lab values (lightness, red-green, yellow-blue axes) or detecting subtle color deviations (critical for automotive coatings, high-end textiles).

  2. Complex color analysis: Required for metallic/pearlescent finishes, transparent materials, or samples with gloss/texture variations.

  3. Compliance and documentation: Essential when precise color data (spectral curves) is needed for quality audits, regulatory compliance, or brand color standardization.
